StateGraph API Reference

The StateGraph class is the core of SpoonOS's graph execution engine, providing a structured way to build complex, multi-step workflows with deterministic control flow.

Class Definition​

from spoon_ai.graph import StateGraph
from typing import TypeVar, TypedDict

State = TypeVar('State')

class StateGraph(Generic[State]):
    def __init__(
        self,
        state_schema: type,
        checkpointer: Optional[Any] = None,
        config_schema: Optional[type] = None
    )

Constructor Parameters​

Required Parameters​

  • state_schema (type): Type definition for the graph state (usually a TypedDict class)

Optional Parameters​

  • checkpointer (Optional[Any]): Checkpointer instance for state persistence
  • config_schema (Optional[type]): Configuration schema for the graph

Core Methods​

Graph Construction​

add_node(node_name: str, node: Union[BaseNode[State], Callable]) -> StateGraph​

Add a node to the graph. Nodes can be either BaseNode instances or callable functions.

Parameters:

  • node_name (str): Unique identifier for the node
  • node (Union[BaseNode, Callable]): Node implementation

Returns:

  • StateGraph: Self for method chaining

Example:

async def analyze_query(state: MyState) -> Dict[str, Any]:
    return {"analysis": "processed"}

graph = StateGraph(MyState)
graph.add_node("analyzer", analyze_query)

add_edge(start_node: str, end_node: str) -> StateGraph​

Add an unconditional edge between nodes.

Parameters:

  • start_node (str): Starting node name
  • end_node (str): Ending node name

Returns:

  • StateGraph: Self for method chaining

Example:

graph.add_edge("analyzer", "summarizer")

set_entry_point(node_name: str) -> StateGraph​

Set the graph's entry point node.

Parameters:

  • node_name (str): Name of the entry point node

Returns:

  • StateGraph: Self for method chaining

Example:

graph.set_entry_point("analyzer")

Compilation and Execution​

compile(checkpointer: Optional[Any] = None) -> CompiledGraph​

Compile the graph into an executable form.

Parameters:

  • checkpointer (Optional[Any]): Optional checkpointer for execution

Returns:

  • CompiledGraph: Compiled executable graph

Raises:

  • GraphConfigurationError: If graph has configuration issues

Example:

compiled_graph = graph.compile()
result = await compiled_graph.invoke({"query": "analyze market"})

State Management​

State Schema Definition​

from typing import TypedDict, Optional, Annotated

class MyState(TypedDict):
    user_query: str
    analysis_result: Optional[str]
    confidence_score: Annotated[float, "0.0 to 1.0"]
    metadata: Annotated[Optional[Dict[str, Any]], None]

State Updates​

Nodes return dictionaries that update the graph state:

async def analysis_node(state: MyState) -> Dict[str, Any]:
    # Process state
    result = await analyze(state["user_query"])

    # Return state updates
    return {
        "results": result,
        "confidence": result.confidence,
        "analysis_type": "comprehensive"
    }

Execution Flow​

Basic Execution​

# Build graph
graph = StateGraph(MyState)
graph.add_node("process", my_node)
graph.add_edge("process", "output")
graph.set_entry_point("process")
graph.add_edge("process", END)

# Execute
compiled = graph.compile()
result = await compiled.invoke({
    "user_query": "Hello Graph!",
    "analysis_result": None
})

print(result["analysis_result"])

With Conditional Routing​

def route_by_complexity(state: MyState) -> str:
    query_length = len(state.get("user_query", ""))
    return "deep_analysis" if query_length > 100 else "quick_answer"

graph.add_conditional_edges(
    "analyze",
    route_by_complexity,
    {
        "deep_analysis": "deep_analyzer",
        "quick_answer": "quick_responder"
    }
)
